橋架的安裝選擇需要多注意哪些事項
山東電纜橋架的安裝選擇需屏蔽電氣干擾的電纜回路，有腐蝕的場所、易燃粉塵場所，應選用無蓋無孔封閉型托盤，當需要因地制宜的場所，宜選用組裝式托盤或有孔托盤及梯架；在容易積灰和其它需遮蓋的環境或戶外場所，宜帶有蓋板。
For the installation of cable tray in Shandong, the cable loop that needs to shield electrical interference, the place with corrosion, the place with combustible dust, should choose the closed tray without cover and hole. When the place needs to adapt to local conditions, it should choose the assembled tray or the perforated tray and ladder; In environments or outdoor areas that are prone to dust accumulation and require covering, it is advisable to have a cover plate.
低壓電力電纜與控制電纜共用同一托盤或梯架時，應選用中間有隔板的托盤或梯架；在托盤、梯架分支、引上、引下處應設適當?shù)膹澩ǎ?/div>
When low-voltage power cables and control cables share the same tray or ladder, a tray or ladder with a partition in the middle should be selected; Appropriate bends should be set up at the branches, leads up, and leads down of trays and ladders;
因受空間條件限制不便裝設彎通或有特殊要求時，可選用軟連接板，鉸接板；伸縮縫應設置伸縮板；連接兩段不同寬度或高度的托盤、梯架可配置變寬或變高板。但在施工中，支、吊架和橋架的選擇應依設計或工程布置條件選擇。
When it is not convenient to install bends due to space limitations or there are special requirements, soft connection plates or hinged plates can be used; Expansion joint shall be provided with expansion board; Connecting two trays or ladders with different widths or heights can be configured with widened or raised boards. However, in construction, the selection of supports, hangers, and cable trays should be based on design or engineering layout conditions.
電纜橋架規格及型號必須符合設計要求，附件齊全；橋架與配件、附件和緊固件各種型鋼均應采用鍍鋅標準件。橋架訂貨或制作應按設計要求進行，不應有誤，應反復校核以免造成浪費。
The specification and model of cable tray must meet the design requirements, with complete accessories; All types of steel sections for bridge and accessories, accessories, and fasteners should be galvanized standard parts. The ordering or production of the bridge should be carried out according to the design requirements, and there should be no errors. It should be repeatedly checked to avoid waste.
各種規格電纜橋架的直線段、彎通、橋架附件及支、吊架立柱及型鋼等有產品合格證，橋架內外應光滑平整，無棱刺，不應有扭曲翹邊等變形現象。
The straight sections, bends, cable tray accessories, supports and hangers, columns and profile steel of various specifications of cable tray shall be provided with product certificates. The inside and outside of the cable tray shall be smooth and flat without burrs, distortion, edge warping and other deformation phenomena.
此外電纜橋架敷設前，應檢查橋架敷設有無與其他設備、管線交叉或重疊無法施工的地方，施工前應與各工種、監理或建設單位及設計單位協商好，并作好記錄，以保證施工順利進行。還有什么問題就來咨詢我們http://www.rtew.cn吧！
In addition, before laying the cable tray, check whether there is any place where the cable bridge laying crosses or overlaps with other equipment and pipelines and cannot be constructed. Before construction, negotiate with each type of work, the supervisor, the construction unit and the design unit, and make records to ensure the smooth construction. If you have any further questions, please feel free to consult us http://www.rtew.cn Come on!
