在電氣布線系統中，電纜橋架是一種用于支撐、保護和管理電纜的結構化裝置，廣泛應用于各類建筑和工業場所。它通過標準化的設計和靈活的組合方式，為電纜提供了有序的敷設通道，既保障了電纜的正常運行，又便于后期的維護和檢修，是現代電氣安裝工程中不可或缺的重要組成部分。

　　In electrical wiring systems, cable trays are structured devices used to support, protect, and manage cables, widely used in various buildings and industrial sites. It provides a safe and orderly laying channel for cables through standardized design and flexible combination methods, ensuring the normal operation of cables and facilitating later maintenance and repair. It is an indispensable and important component of modern electrical installation engineering.

　　從定義來看，電纜橋架是由支架、托臂和安裝附件等組成的剛性結構系統，主要用于承載電力電纜、控制電纜、通信電纜等各類線纜。與傳統的穿管敷設方式不同，電纜橋架采用開放式或半開放式結構，能讓電纜有序排列并暴露在外（部分類型帶有蓋板），不僅便于散熱，還能直觀地觀察電纜的運行狀態，及時發現破損、老化等問題。其設計遵循標準化原則，不同規格、型號的橋架可通過連接件靈活組合，適應不同的敷設路徑和空間要求，滿足多樣化的布線需求。

　　From a definition perspective, cable tray is a rigid structural system composed of brackets, support arms, and installation accessories, mainly used to carry various types of cables such as power cables, control cables, communication cables, etc. Unlike traditional conduit laying methods, cable trays adopt an open or semi open structure, which allows cables to be arranged in an orderly manner and exposed to the outside (some types have cover plates). This not only facilitates heat dissipation, but also allows for intuitive observation of cable operation status, timely detection of damage, aging, and other issues. Its design follows the principle of standardization, and different specifications and models of cable trays can be flexibly combined through connectors to adapt to different laying paths and space requirements, meeting diverse wiring needs.

　　電纜橋架的基本結構包括主體框架和輔助配件。主體框架通常由托盤、梯架或槽式殼體構成，是承載電纜的核心部分：托盤式橋架由底部帶有散熱孔的鋼板或鋁合金板制成，結構輕便，適合敷設截面較小的電纜；梯架式橋架由兩側的立板和中間的橫檔組成，形似梯子，透氣性好，承載能力強，多用于大直徑電力電纜的敷設；槽式橋架則是封閉或半封閉的殼體結構，能為電纜提供更好的防護，適合在灰塵多、潮濕或有腐蝕性的環境中使用。輔助配件包括支架、托臂、連接件、蓋板等，支架和托臂用于將橋架固定在墻體、天花板或地面上，確保橋架安裝牢固；連接件用于橋架之間的拼接，保證敷設路徑的連續性；蓋板則可根據需要加裝，起到防塵、防水、防外物撞擊的作用。

　　The basic structure of cable tray includes the main frame and auxiliary accessories. The main frame is usually composed of trays, ladders, or trough type shells, and is the core part that carries cables: tray type cable trays are made of steel plates or aluminum alloy plates with heat dissipation holes at the bottom, which are lightweight in structure and suitable for laying cables with smaller cross-sections; The ladder style bridge is composed of two vertical plates on both sides and a crossbar in the middle, resembling a ladder, with good breathability and strong load-bearing capacity. It is commonly used for laying large-diameter power cables; Slot type cable trays are enclosed or semi enclosed shell structures that provide better protection for cables and are suitable for use in dusty, humid, or corrosive environments. Auxiliary accessories include brackets, support arms, connectors, cover plates, etc. The brackets and support arms are used to fix the bridge to the wall, ceiling, or floor, ensuring that the bridge is installed firmly; Connectors are used for splicing between cable trays to ensure the continuity of the laying path; The cover plate can be installed as needed to prevent dust, water, and external object impact.

　　根據材質的不同，電纜橋架可分為多種類型，以適應不同的使用環境。鋼制電纜橋架是常見的類型，采用冷軋鋼板加工而成，通過鍍鋅、噴漆等表面處理提升耐腐蝕性，具有強度高、適中的特點，適合一般工業與民用建筑。鋁合金電纜橋架重量輕、耐腐蝕性強，表面經陽極氧化處理后美觀耐用，多用于潮濕環境或?qū)χ亓坑袊?yán)格限制的場所，如高層建筑、化工車間等。玻璃鋼電纜橋架由玻璃纖維和樹脂復合而成，具有優異的耐酸堿、抗老化性能，且不導電、不導熱，適合在有強腐蝕介質的環境中使用，如電鍍車間、污水處理廠等。此外，還有防火電纜橋架，其表面涂覆防火涂料或采用阻燃材料制造，能在火災發生時延緩火勢蔓延，為電纜的應急供電爭取時間，適用于消防系統等重要電路的敷設。

　　According to the different materials, cable trays can be divided into various types to adapt to different usage environments. Steel cable trays are the most common type, processed from cold-rolled steel plates and improved in corrosion resistance through surface treatments such as galvanizing and painting. They have the characteristics of high strength and moderate price, and are suitable for general industrial and civil buildings. Aluminum alloy cable trays are lightweight, highly corrosion-resistant, and have a beautiful and durable surface after anodizing treatment. They are commonly used in humid environments or places with strict weight restrictions, such as high-rise buildings and chemical workshops. Glass fiber reinforced plastic cable tray is composed of glass fiber and resin. It has excellent acid and alkali resistance, anti-aging performance, and does not conduct electricity and heat. It is suitable for use in environments with strong corrosive media, such as electroplating workshops, sewage treatment plants, etc. In addition, there are fire-resistant cable trays, whose surfaces are coated with fire-resistant coatings or made of flame-retardant materials, which can delay the spread of fire in the event of a fire, buy time for emergency power supply of cables, and are suitable for laying important circuits such as fire protection systems.

　　電纜橋架的主要作用體現在保護、管理和優化電纜敷設三個方面。在保護方面，它能將電纜與外界環境中的機械損傷、化學腐蝕、灰塵水汽等隔離開來，減少電纜因外力或環境因素導致的故障，延長電纜的使用壽命。在管理方面，橋架通過分層、分區域的設計，將不同功能、不同電壓等級的電纜分開敷設，避免了電纜之間的相互干擾，尤其對控制電纜和通信電纜而言，能減少信號干擾，保證傳輸質量。在優化敷設方面，橋架可根據建筑結構和布線需求，靈活設計成水平、垂直、轉彎、爬坡等多種路徑，充分利用建筑空間，使電纜敷設更加規整美觀，避免了線纜雜亂無章的現象，同時為后期的擴容和改造提供了便利，只需增加橋架單元即可新增電纜。

　　The main functions of cable trays are reflected in three aspects: protection, management, and optimization of cable laying. In terms of protection, it can isolate cables from mechanical damage, chemical corrosion, dust and water vapor in the external environment, reduce cable failures caused by external forces or environmental factors, and extend the service life of cables. In terms of management, cable trays are designed with layers and zones to separate cables of different functions and voltage levels, avoiding mutual interference between cables. Especially for control cables and communication cables, it can reduce signal interference and ensure transmission quality. In terms of optimizing cable laying, cable trays can be flexibly designed into various paths such as horizontal, vertical, turning, climbing, etc. according to the building structure and wiring requirements, fully utilizing the building space to make cable laying more orderly and beautiful, avoiding the phenomenon of disorderly cables, and providing convenience for later expansion and renovation. Only by adding cable tray units can new cables be added.
